SpecificationsÂ
Stator Diameter: 25.0 mm (0.98 in)Â
Stator Thickness: 20.0 mm (0.79 in)Â
No. of Stator Arms: 12Â
No. of Magnet Poles: 10Â
Motor Wind: 8 Turn DeltaÂ
Motor Wire: 11-Strand 0.25mmÂ
Motor Kv: 1880 RPM / VoltÂ
No-Load Current (Io): 2.25 Amps @ 10 voltsÂ
Motor Resistance (Rm): 0.026 OhmsÂ
Max Continuous Current: 38 AmpsÂ
Max Continuous Power: 800 WattsÂ
Weight: 104 Grams (3.64oz)Â
Outside Diameter: 31.5 mm (1.24 in)Â
Shaft Diameter: 3.5 mm (0.14 in)Â
Body Length: 39.6 mm (1.56 in)Â
Overall Shaft Length: 57.5 mm (2.46 in)Â
Max LiPo Cell:Â 6sÂ
Motor Timing: 5°Â
Drive Frequency:Â 8kHzÂ
This product was added to our catalog on January 12, 2018
